FITTED EQUIPMENT
175
Omni-vent (when fitted)
Use rooflight
• Close the lid before driving
• To take away the roller blind, unscrew and
click the frame off the side of the knob.
Use of the ventilation
• The ventilator is started by the soft switch
S2. The middle LED light lights up and the
ventilator starts in comfort mode, this is the
lowest speed (extract). See fig 18.
• By pushing on the switch S1 (extract) or
S3 (intake), the airflow can be adjusted in 6
steps. See table 19.
*MIN = 3,7 m
3
/min (2 W - 0,17 A)
*MAX = 24 m
3
/min (86 W - 7,20 A)
• In order to save the battery, the speed drops
from position 6 to the lowest position after
one hour of use.
• It is possible to allow the ventilator to work
for 5 minutes on the highest speed (boost).
To do this push for 3 seconds on the button
S1 (extraction) or S2 (intake). After 5 minutes
the ventilator returns to its previous speed
setting. See table in fig 20.
OMNIVENT
