FITTED EQUIPMENT
168
Heki-2 roof light (when fitted)
The lift/tilt roof light can be set in 3 positions by
means of pneumatic springs.
Position 1 lifts the pane 12mm without allowing
rain to enter the caravan.
Position 2 sets the pane to a 150mm opening
and locks with a bar.
Position 3 opens the pane through 55°.
A fully adjustable flyscreen and black-out
screen are built into the inner frame. The
flyscreen can be drawn independently and the
black-out screen is variable for partial or full
black-out.
Forced ventilation functions via a brush lined
duct instead of a ventilated pane.
A cover hood can be fitted for winter
protection.
Heki-2 roof lights provide 13,200mm2 of
fixed ventilation.
Heki 4 Remote Control
(when fitted)
The remote control is ready for use after
inserting the two batteries and functions within
a maximum distance of 1.5m from the Heki
rooflight sensor located near the red control
lamp on the forward edge of the inner frame.
When the power is turned on for the first time
or after an interuption in the power supply, the
red control lamp will blink. Hold the remote
close to the control lamp and press any of the
buttons to turn the control lamp off. The light
will remain illuminated if the rooflight is not
completely closed.
Opening/closing the acrylic dome
Hold the remote control in the direction of
the red control lamp. Press button 1
temporarily and the dome will open to 70
degrees. To stop the dome fully opening press
button 1 again before it reaches 70 degrees.
Press and hold button 2
to close the roof
Lighting (optional)
Buttons 3 and 4 operate the optional lights.
ROOFLIGHTS
Red Control Lamp
