FITTED EQUIPMENT
177
Digital Reversing System
(when fitted)
The Caravan Reversing Camera Kit features
an LCD monitor for use as a reversing / rear
view aid, and also includes satellite navigation
software.
•100% digital car / caravan monitor kit
•Interference-free wireless transmission
•5” colour LCD screen
• Infra-red night vision
Cautions: This reversing / rear view camera
system is provided as an aid only. It should
not be relied upon as the sole indication of
your vehicle position or the position of other
vehicles or any obstacles. The supplier,
manufacturer or supplying dealer accepts
no responsibility for damage or injury to
property or persons following the use or
misuse of this equipment.
System Operation
The monitor and camera system is provided
as an aid when reversing your caravan and
can also be used to provide an additional view
from the rear of the caravan whilst driving.
It should not be relied upon as the sole
indication of your vehicle position or the
position of other vehicles or any obstacles.
When reversing or manoeuvring please
ensure the area around your caravan is clear
from obstructions, and do not wholly rely on
the camera view, use your mirrors and seek
assistance as required.
Caravan Camera
The camera fitted to the rear of the caravan
has no serviceable parts, however the
following precautions should be observed.
• Check that the camera lens is clean as dirt
can obscure the view.
• Never use a power washer or water jet to
clean the camera or transmitter.
Connecting the Car
Before you can use the monitor with the
camera you need to connect your caravan to
the car with the 13 pin towing connector.
When the car engine is started the rear camera
will receive power and switch on automatically.
Connecting the Car
Before you can use the monitor with the
camera you need to connect your caravan to
the car with the 13 pin towing connector.
When the car engine is started the rear camera
will receive power and switch on automatically.
Installing the Monitor in the towcar
The monitor has various features you should
be familiar with for correct operation.
Firstly attach the mount to the rear of the
monitor and connect the car power cable. The
monitor mounting plate clips to the rear of the
monitor. The windscreen mounting then clips
onto the mounting plate. The power cable
plugs into the mini-USB socket on the side of
the monitor with the other end plugging into
the car power socket.
The monitor has an internal rechargeable
battery which will last for around 1 hour when
used without the power cable. This battery is
charged when the power cable is connected.
Charging is indicated by a red LED on the side
of the monitor.
Now attach the monitor mount to the
windscreen using the suction mounting.
• Do not position the monitor in a place that
will block the drivers’ view of the road.
• Do not block air bags or other dashboard
features.
• Safely position the power cable to prevent
entanglement or cable damage.
• Ensure the monitor is secure. The suction
mount can be moistened to enhance the
seal to the windscreen.
REAR VISION CAMERA
