FITTED EQUIPMENT
134
If the battery voltage is too low, an acoustic
signal (whistle tone) sounds every 15 seconds.
Then replace the batteries in the battery
compartment.
Inserting / changing the batteries
Switch off the refrigerator, as described on
page 139 Shutting off the refrigerator.
Fig. 16
Opening right battery compartment
Fig. 15
Opening left battery compartment
open
press
press
open
1
1
2
Note: Batteries (8 x AA 1.5V) are not
included!
! WARNING:
• Observe the correct polarity!
• Do not connect non-rechargeable
batteries to a charger.
• Remove rechargeable batteries from the
battery compartment before charging.
• Avoid short circuits on the contacts in the
battery compartment!
• Remove discharged batteries.
• Remove the batteries from the battery
compartment if the refrigerator will not be
used for a long time.
• Do not mix different types of batteries.
Frame heating (fridge freezer models only)
All fridge freezer models are equipped with
a frame heating (12VDC/3,5W) around the
freezer compartment. During summer months
with high temperatures and humidity the metal
frame may have water droplets forming. To
evaporate these droplets switch on the frame
heating with button (6).
Fig. 18
6
8
The operating time of the frame heater can
be set to 2 hours, 5 hours or continuous
operation. After selecting the operating time
using the button (6), the temperature level
indicator (8) is extinguished for a short time to
show the set operating time for a few seconds.
The display then returns to the temperature
level indicator.
Operating time: 2 hours
Press button (6) once Display
1x
Operating time: 5 hours
Press button (6) twice Display
2x
Permanent operation
Press button (6) three times Display
3x
DOMETIC REFRIGERATOR
Fig. 17
Fig. 18
Fig. 19
