FITTED EQUIPMENT
138
Refrigerator compartments
5
1
6
7
2
3
4
Fig. 37
1 - Freezer compartment:
already frozen food (deep-frozen food)
2 - Middle compartment:
Dairy products, convenience food
3 - Bottom compartment:
Meat, fish, food for defrosting
4 - Vegetable compartment:
Salads, vegetables, fruit
5 - Top door shelf:
Eggs, butter
6 - Middle door shelf:
Cans, dressings, ketchup, jam
7 - Bottom door shelf (drinks
compartment):
Drinks in bottles or bags
Positioning the storage racks
The storage racks may be pulled out by
loosening the two locking devices (1)
underneath. For loosening pull the slider to the
middle, for fastening pull them sidewards.
Two of the storage racks are secured. In this
way inadvertent entrapment and suffocation
of children is prevented, if the storage racks
are removed. To protect children it must be
avoided to create space for children in the
cooling compartment.
! WARNING: Do not remove these
storage racks. Thus children have no space
to be entrapped in the refrigerator.
If it is necessary to remove these storage racks
(i.e. for cleaning) loosen the locking pins (2) at
first as shown, by means of a suitable screw
driver.
Put in place the locking pins after removing the
storage racks.
Fig. 26
1
1
2
DOMETIC REFRIGERATOR
Fig. 33
Fig. 34
