FITTED EQUIPMENT
182
SERVICE DOORS
Seitz Service door operating
instructions (when fitted)
To open the door put the key in the lock
fig 1.
To close the door push the spring stay
in to fold away (when fitted fig 4.) and
close the door applying pressure to the
hatch until you hear the locks click in to
place fig 5.
Turn in an anti-clockwise direction until the
locking handle is released fig 2.
Insert the key fig 6.
Remove the key and turn the handle in a
clockwise direction fig 3.
Turn anti-clockwise fig 7.
open the door until the sprung stay en-
gages fig 4 (Not fitted to the toilet door).
Then remove the key fig 8 and lock by
turning the handle anti-clockwise and
pushing back in to place. Note the han-
dle will not push back in to place until all
the locks are closed figure 5.
