10.4. Exhaust grilles valid as per current technical report (France)
Bahia Curve in individual housing Technical Report #14.5 /17-2266
Hygro B Bahia Curve exhaust grilles
Type of dwelling Kitchen Bathroom1 Bathroom2
Other
bathroom 1
Bathroom
with WC 1
Other
bathroom
with WC
WC
Wash-
up
room*
F1 C32
B21
B21
BW21 BW21
W13
B21
F2 C36
F3
C21
F4
F5
F6 (2BWC) or (1B 1WC 1BWC)
B21 B21 BW22 BW22
F7 and + (2BWC) or (1B 1WC 1BWC)
F6 (2B 1WC)
B21
B23 BW21 BW21
F7 and + (2B 1WC)
F6 (1B 1WC 1SDE) / / / / B23
Hygro A Bahia Curve exhaust grilles
Type of dwelling Kitchen Bathroom1 Bathroom2
Other
bathroom
Bathroom
with WC 1
Other
bathroom
with WC
WC
Wash-
up
room*
F1 C32
B21
/
B21 or
B22**
BW21 BW21
W13
B21
F2
C21
F3
B22
BW22 BW22 or BW21**
F4
F5
F6 (2BWC) or
(1B 1WC and 1BWC) or (2B 1WC)
B23 if bathroom
2 in
(2 bathrooms
+ 1 WC)
F7
F6 (1B 1WC 1SDE) / / / / B23
** Refer to Technical Report for details of Bahia Curve configurations in collective housing #14.5/17-2267
Bahia Curve in collective housing Technical Report #14.5 /17-2267
Hygro B Kitchen
Bathroom
1
Bathroom
2
Other
bathroom 1
Bathroom
with WC 1
Other bathroom
with WC
WC
Wash-up
room*
F1 C32
B21
B21
BW21 BW21
W13 B21
F2 C36
F3
C21
F4
F5 BW21 BW21
F6 (2BWC) or (1B 1WC 1BWC)
BW22 BW22
F7 and + (2BWC) or (1B 1WC
1BWC)
F6 (2B 1WC)
B21 B23 BW21 BW21
F7 and + (2B 1WC)
*Wash-up room: room other than the kitchen or WC, fitted with a water point but without bath or shower (cellar, laundry room, etc.)
