aldes T.Flow Hygro+ - Installing the Water Heater

44
600 mm mini.
avec cloisons amovibles pour maintenance
600 mm mini.
573 mm
566 mm
582 mm
3.3. Installing the water heater
There is no need for access to the heat pump in the upper part. It is therefore pointless and strongly advised not to remove
the top cover.
All the hydraulic and electrical connections can be accessed vis the front side (with no need to remove the front cover).
T.Flow
®
Hygro+
The water heater must be installed on a smooth, horizontal surface (+/- 1°). Otherwise, it must be levelled by
wedging its legs.
Problems with condensate evacuation may occur without this precaution.
Kg
MIN.
350
if walls can be removed for maintenance
