T.Flow
®
Nano Wall mounted (see Installation template 35033150)
The wall-mounted water heater must comply with the requirements of NF DTU 60.1.
It can be mandatory to use a tripod for the installation depending on the type of wall.
The water heater must be fixed to the wall with the appropriate anchors and screws for the wall and the weight of
the equipment (in accordance with standard EN 60-335-1).
1- Make sure that the wall is suitable for this type of installation. Otherwise, a tripod installation is mandatory.
Guide weight of the water heater filled with water
B100 T.Flow Nano: 176 kg
B100 FAN-T.Flow Nano: 178 kg
2- Drill the holes as shown opposite.
3- Insert the anchors and the appropriate screws or threaded rods
4a- Position the product
4b- Tighten the screws or the nuts + 25 mm washer min.
if walls can be removed for maintenance
