2. DESCRIPTION
2.1. Principle of operation
The T.Flow
®
Hygro+/T.Flow
®
Nano solutions renew the air in new or existing dwellings, to improve air quality and protect the
construction (SELF-BALANCING or HUMIDITY-CONTROLLED unidirectional CMEV).
The heat pump built into the system uses the energy contained in the extract air to produce domestic hot water up to a temperature
of 55°C (65°C with electrical boost). The hot water produced is stored in a tank.
The hot water production performances are only guaranteed if the ventilation is installed in accordance with the rules in force and by
selecting the air grilles and inlets defined for each system.
These systems are intended for individual or collective housing (no fan is fitted to the model intended for collective applications).
2.2. Range
Application Solution Description Code
Individual houses
CMEV Self-balancing/
Humidity-controlled
B200-FAN_T.Flow
®
Hygro+
(with built-in fan)
11023198 (not connected)
11023384 (connected)
CMEV Self-balancing/
Humidity-controlled
B100-FAN_T.Flow
®
Nano
(with built-in fan)
11023394 (not connected)
1123396 (connected)
Collective housing
CMEV Self-balancing/
Humidity-controlled
B200_T.Flow
®
Hygro+
(without fan)
11023199 (not connected)
11023385 (connected)
CMEV Self-balancing/
Humidity-controlled
B100_T.Flow
®
Nano
(without fan)
11023395 (not connected)
11023397 (connected)
Connected T.Flow
®
comprise an unconnected T.Flow
®
(11023198, 11023394, 11023199 or 11023395) and an AldesConnect
TM
Box
(11023386).
2.3. Technical details
T.Flow Hygro + T.Flow Nano
Dimensions (mm) H 1941 x w 566 x D 573 H 1311 x w 566 x D 582
Tank
Capacity 200 litres, enamelled steel Capacity 100 litres, enamelled steel
Service pressure 7 bar
Insulation 55 mm thick, polyurethane foam without CFC
DHW Cold water inlet and hot water outlet connections G3/4” (dielectric connectors supplied but not mounted)
Anti-corrosion protection 1 titanium impressed current anode + 1 magnesium starter anode
Electrical connection
(voltage/frequency)
230 V single phase/50 Hz
IP rating IPX1
Heating element Steatite 1500W
Trim Painted steel sheet
Heat pump
Variable speed compressor Inverter
Refrigerant R513a *(PRG: 631).
Initial load: 650 g, i.e. 0.41 tCO
2
eq.
Refrigerant R513a *(PRG: 631).
Initial load: 580g, i.e. 0.37 tCO
2
eq.
Heat pump use range (extract air temperature): min. 10°C to max. 35°C
CMEV
Micro-watt low-consumption fan
G4 pleated filter**
Aeraulic connections Ø160 mm
Average airflow range from 49.1 to 222.8 m
3
/h Average airflow range from 27.8 to 137.5 m
3
/h
Weight
T.Flow
®
Hygro+ Collective housing: 77Kg
T.Flow
®
Hygro+ Individual housing: 79Kg
T.Flow
®
Nano Collective housing: 69Kg
T.Flow
®
Nano Individual housing: 71Kg
* Fluorinated greenhouse gas contained within a hermetically sealed unit.
** Filter class G4 as per EN 779 and ISO Coarse 65% as per ISO 16890.
