1197 mm
560 mm
1197 mm
582 mm
566 mm
T.Flow
®
Nano Tripod installation
When installing the T.Flow
®
Nano on a tripod, it is mandatory to fasten the product to the wall (at least on top
fastening support).
1- Drill the holes
2- Insert the anchors and the
appropriate screws or threaded
rods
3- Position the product on its tripod.
4- Tighten the screws or the nuts +
25 mm washer min.
if walls can be removed for maintenance
