6. Insert the quick-release levers from the outside through the holes in the guide
bar and guide bar frame (see Fig. 3).
7. Insert the bolts
from the inside onto the threads of the quick-release levers
and turn in the quick-release levers until they can be secured by closing them.
8. Remove the cable clamps
from the guide bar frame.
9. Connect the cable
to the guide bar frame and replace the cable clamps so
that the cable is in the recess.
10. Adjust the guide bar frame to the desired angle and secure it by turning the
quick-release lever tight again.
Folding up the guide bar
When transporting or storing the lawnmower, the handlebar can be folded to save
space.
1. Fold the quick-release levers
upwards.
2. Turn out the quick-release levers so that there is clearance between the guide
bar
and the guide bar frame
.
3. Fold the guide bar upwards.
4. Turn the quick-release levers back in and fold them downwards to fix the guide
bar.
Inserting/removing the rechargeable battery
1. Open the battery compartment by lifting the locking mechanism and folding the
safety cover
upwards (see Fig. 4).
2. Insert the rechargeable battery by guiding it into the insertion shaft on the rail
until it locks in place. The contacts must be pointing downwards.
3. Fold the safety cover shut again.
In order to remove the battery again, you must press the unlocking mechanism
.
Operation
WARNING!
Risk of injury!
Improper handling of the lawn mower can cause injuries. The
rotating blades can cause severe cuts and even sever body parts.
Before
first use
16
