Cable-connection diagram 1 W001
W002 W003 W101
Location
Mounting
Title
Emmie w. heater
Revised date
06 2
3
Next page
Page
2015-03-26
Internal targetsExternal targets
Shield SH shall be connected to cable glands,
except for power supply cables, they shall be connected to PE bar.
Page.26/:254
IF2:1
+CP01
A1
1
+CP01
-OP1
Ethernet
to OP
1
11
Page.23/:221
11
Page.21/:201
22
Page.21/:201
GNYEGNYE
Page.21/:201
PE21
+CP01
X1
PENL
+PS
-MAINS
Power Supply:
1x230V 50/60Hz
(Max fuse 10A)
Option:
1x100/110/120V
50/60Hz (Max
fuse 10A)
W001
PEWV
SHSH
Page.23/:222
SHU
+CP01
U2
+Field
-SH
Shield connected in EMC cable gland
Pump
W003
11
Page.24/:232
22
Page.22/:211
33
Page.22/:211
PEPE
Page.22/:211
PEW1V1U1
+Field
-M1
22
Page.23/:221
33
Page.23/:221
PEPE
Page.23/:221
PEV1W1U1
+Field
-M2
22
Page.24/:232
21
+Field
-R1
11
Page.22/:211
5
GNYEGNYE
Page.24/:232
PE6
+CP01
X1
PE
+Field
-R1
SHSH
Page.24/:232
+CP01
SH
+Field
-SH
Heater
W101
PEW2V2
SHSH
Page.22/:212
SHU2
+CP01
U1
+Field
-SH
Shield connected in EMC cable gland
Separator
W002
