3 Installation
Study the instructions carefully and pay special attention to the warnings!
The direction of rotation of the impeller can be checked by observing the direction of rotation of the motor fan.
- See the indication label on the pump.
Step 3
Check that the flow direction is correct.
O: Outlet
I: Inlet
3003-0089
I
O
9
Step 4
1. Ensure that the pipelines are routed correctly.
2. Ensure that the connections are tight.
3. Remember seal rings. Few bends
3003-0090
12
