3 Installation
Study the instructions carefully and pay special attention to the warnings!
The direction of rotation of the impeller can be checked by observing the direction of rotation of the motor fan.
- See the indication label on the pump.
Step 5
Avoid stressing the pump.
Piping system must be self-supported.
Pay special attention to:
-Vibrations.
- Thermal expansion of the tubes.
- Excessive welding.
- Overloading of the pipelines.
Example of piping system self-supported.
3003-0091
!
3003-0092
Step 6
Ensure correct alignment of pump inlet and outlet with piping
system.
Alignment can be done by adjusting the pump legs.
3003-0093
3003-0094
13
