3 Installation
Study the instructions carefully and pay special attention to the warnings!
The direction of rotation of the impeller can be checked by observing the direction of rotation of the motor fan.
- See the indication label on the pump.
Centre of inlet and outlet to be aligned with centre of piping system.
3003-0095
No gaps between connections on pump inlet and inlet pipe, and pump outlet and outlet pipe.
3003-0096
Angel between connections on pump inlet and inlet pipe, pump outlet and outlet pipe not allowed.
3003-0097
14
