Alfa Laval T2 User Manual

Product
(AQ-
model)
Frame Type
L1
Unholed pres-
sure plate
L1
Holed pressure
plate
W1 H1
T8
(AQ3)
FD/FG/FM PED/ALS/ASME
A + 310
(A + 12.20)
A + 350
(A + 13.77 )
550
(21.65)
925
(36.41)
T10
(AQ4T)
FD/FG/FM PED/ALS/ASME
A + 390
(A + 15.35)
A + 390
(A + 15.35)
600
(23.62)
1119
(45.05)
TL10
(AQ4L)
FM PED/ALS/ASME A+390 A+390 628 1997
FG PED/ALS/ASME A+400 A+400 656 1346
FD PED/ALS/ASME A+420 A+420 656 1346
M10
(AQ4)
FM
PED/ALS/ASME
Static measure-
ments, depends
on A mesure
Static measure-
ments, depends
on A mesure
600 1095
FG PED/ALS/ASME
Static measure-
ments, depends
on A mesure
Static measure-
ments, depends
on A mesure
600 1095
FD SA+TUV
Static measure-
ments, depends
on A mesure
Static measure-
ments, depends
on A mesure
600 1015
FD ASME
Static measure-
ments, depends
on A mesure
Static measure-
ments, depends
on A mesure
600 1095
T15
(AQ6T)
FM PED/ALS
A + 370
(A + 14.56)
A + 370
(A + 14.56)
742
(29.21)
1879
(73.97)
FG
PED/ALS
A + 480
(A + 18.89)
A + 480
(A + 18.89)
808
(31.81)
1919
(75.55)
ASME
A + 460
(A + 18.11)
A + 460
(A + 18.11)
808
(31.81)
1904
(74.96)
FD ASME
A + 480
(A + 18.89)
A + 480
(A + 18.89)
808
(31.81)
1919
(75.55)
FS
PED/ALS
A + 500
(A + 19.68)
A + 500
(A + 19.68)
808
(31.81)
1919
(75.55)
ASME
A + 520
(A + 20.47)
A + 520
(A + 20.47)
828
(32.59)
1919
(75.55)
TL15
(AQ6L)
FM
PED/ALS/ASME A+360 A+360 760
2710 (2775
when rein-
forced CB)
FG PED/ALS/ASME A+450 A+450 820
2710 (2775
when rein-
forced CB)
FD PED/ALS/ASME A+480 A+480 820
2710 (2775
when rein-
forced CB)
MK15
FG PED/ALS/ASME A+380 A+470 820 1550
FD PED/ALS/ASME A+420 A+530 820 1550
200003991-1-EN-GB16
6 MeasurementsEN
