Alfa Laval T2 - Page 17

Product
(AQ-
model)
Frame Type
L1
Unholed pres-
sure plate
L1
Holed pressure
plate
W1 H1
T20
(AQ8)
FG PED/ALS/ASME A+460 A+460 920 2200
FD ASME A+560 A+560 920
2235 (2385
when rein-
forced CB)
TK20
FD ALS+PED - A+510 925 1560
FD ASME - A+520 925 1560
T21
(AQ8T)
FD
PED/ALS
A + 520
(A + 20.47)
A + 570
(A + 22.44)
950
(37.40)
2248
(88.50)
ASME
A + 557
(A + 21.92)
A + 607
(A + 23.89)
950
(37.40)
2248
(88.50)
FG PED/ALS
A + 480
(A + 18.89)
A + 520
(A + 20.47)
950
(37.40)
2210
(87.00)
FM PED/ALS
A + 420
(A + 16.53)
A + 495
(A + 19.48)
950
(37.40)
2157
(84.92)
FT
ALS
A + 582
(A + 22.91)
A + 629
(A + 24.76)
950
(37.40)
2248
(88.50)
ASME
A + 592
(A + 23.30)
A + 634
(A + 24.96)
940
(37.00)
2248
(88.50)
T25
(AQ10T)
FD
PED/ALS
A + 555
(A + 21.85)
A + 555
(A + 21.85)
1070
(42.12)
2771
(109.09)
ASME
A + 600
(A + 23.62)
A + 600
(A + 23.62)
1090
(42.91)
2771
(109.09)
FG
PED/ALS
A + 520
(A + 20.47)
A + 520
(A + 20.47)
1070
(42.12)
2721
(107.12)
ASME
A + 520
(A + 20.47)
A + 520
(A + 20.47)
1070
(42.12)
2721
(107.12)
FM
PED/ALS
A + 505
(A + 19.88)
A + 505
(A + 19.88)
1070
(42.12)
2721
(107.12)
ASME
A + 505
(A + 19.88)
A + 505
(A + 19.88)
1070
(42.12)
2721
(107.12)
FS
PED/ALS
A + 590
(A + 23.22)
A + 590
(A + 23.22)
1070
(42.12)
2771
(109.09)
ASME
A + 640
(A + 25.19)
A + 640
(A + 25.19)
1090
(42.91)
2771
(109.09)
200003991-1-EN-GB 17
Measurements 6 EN
