Alfa Laval T6 User Manual

5 Dimensions
LC
H1
A
W1
W2
H2
L1
L2
B
A = Plate pack length
B = Foot print length
LC = Length of the carrying bar
H1 = Height of the insulation
H2 = Height of the drip tray
L1 = Length of the insulation
L2 = Length of the drip tray
W1 = Width of the insulation
W2 = Width of the drip tray
200002797-1-EN-GB 13
EN
