7 Parts list and service kits
Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine
spare parts.
Parts list
Pos. Qty Denomination
15 1
Plug
38 ♦
1
O-ring, EPDM
39 2
O-ring, EPDM
40
1
O-ring, EPDM
41 1
Flushing tube
42
1
Spindle liner
43 2
Clamp
44 1
Lock
45 1
Guide ring, PTFE
46 ♦
1
O-ring, EPDM
47 ♦ 1
O-ring
48
1
Upper seal
ing element
49 ♦
1
Lip seal
52
1
O-ring
54 1
Guide ring, PTFE
55
1
Upper plug
56 ♦
1
Seal ring
57 ♦
1
Lip seal
58
1
Spray nozzle, PVDF
66 2 Flushing tube
67 ♦ 2
O-ring, EPDM
68
1
Drain
69
1
Nozzle
70 2 Fl
ushing tube
71 ♦
2
O-ring, EPDM
72
1
Drain
73
1
Nozzle
74 ♦ 1
Seal ring
75
1
Lower plug
76 ♦
1
O-ring
77 ♦
1
Lip seal
78 ♦
1
O-ring, EPDM
79
1
Lower sealing element
80
1
Guide ring, PTFE
81
1
Cover
