7 Parts list and service kits
Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine
spare parts.
Service kits
Denomination
DN/OD 51
DN 50
Seat ø53.3
DN/OD 63.5
DN/OD 76.1
DN 65/DN 80
Seat ø81.3
#2
DN/OD 101.6
DN 100
Seat ø100.3
#1
DN/OD 101.6
DN 100
Seat ø115.3
DN 125
DN 150
Seat ø115.3
♦
Service kit, EPDM ............................
9611921695 9611921697 9611926358 9611921699 9611926049
♦
Service kit, NBR .............................
9611921701 9611921703 9611926359 9611921705 9611926050
♦
Service kit, FPM ..............................
9611921707 9611921709 9611926360 9611921711 9611926051
♦
Service kit, HNBR ............................
9611921713 9611921715 9611926361 9611921717 9611926052
For mixed size housings, the service kit is determined by the smallest size connection on the valve.
One exception is any housing with 6” connections will always refer to the 6” service kits listed below:
♦
Service kit, EPDM ............................
9611926129 9611926193 9611926398 9611926257
♦
Service kit, NBR .............................
9611926130 9611926194 9611926399 9611926258
♦
Service kit, FPM ..............................
9611926131 9611926195 9611926400 9611926259
♦
Service kit, HNBR ............................
9611926132 9611926196 9611926401 9611926260
Parts marked with
♦ are included in the service kit.
#1 = Serial no. below 1030000 - manufactured before October 1st 2003
#2 = Serial no. above 1030000 - manufactured after October 1st 2003
NOTE!
If different connection size on upper and lower body, except for size 6", it is always the smallest body that determines the service kit.
If clamped valve body an extra O-ring (pos. 52) is required.
If SpiralClean in leakage chamber extra O-rings (2x pos. 39 and 1x pos. 40) is required.
Spare parts for mix size please refer to Configurator in AL Anytime
NOTE!
All FPM service kits are supplied with EPDM seal ring, pos. 74.
