AlgoForce E1500 plus - Assembly

AlgoForce E1500
8
Assembly
① Plug the USB cable and headphone extension cable into the control box.
Note: To keep the exposed length of the headphone extension cable short, you can store any excess
cable inside the handle, as illustrated in the following picture.
② Secure the control box to the shaft using two M5 screws.
③ Attach the armrest to the sliding rail.
④ Secure the power bank with the straps.
⑤ Connect the USB cable to the power bank.
8
8
8
7
6
3
4
5
2
9
1
