7 In sequential order as indicated on the processor cooling-assembly, tighten
the captive screws that secure the processor liquid-cooling assembly to the
system board.
8 Connect the processor liquid-cooling assembly fan cable to the system board.
9 Connect the processor liquid-cooling assembly pump-fan cable to the system
board.
Post-requisites
1 Replace the memory modules.
2 Replace the left and right side-panels. See “Replacing the side panels”.
3 Replace the stability foot.
102
