Replacing the battery case
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your computer.
For more safety best practices, see the Regulatory Compliance home
page at
www.dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the battery case with the screw holes on the chassis.
2 Replace the two screws (#6-32x5.2) that secure the battery case to the
chassis.
3 Route the battery-case cable through the routing guides on the chassis.
4 Connect the battery-case cable to the I/O board.
Post-requisites
1 Replace the battery.
2 Replace the right side-panel. See “Replacing the side panels”.
3 Replace the stability foot.
40
