Removing the right AlienFX side-

panel connector

WARNING: Before working inside your computer, read the safety

information that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your

computer, follow the instructions in After working inside your computer.

For more safety best practices, see the Regulatory Compliance home

page at

www.dell.com/regulatory_compliance.

Prerequisites

1 Remove the stability foot.

2 Remove the left and right side-panels. See “Removing the side panels”.

Procedure

1 Lay the chassis on the left side.

2 Disconnect the right AlienFX side-panel cable that connects the right

AlienFX side-panel connector to the I/O board. See “I/O-board

components”.

3 Remove the right AlienFX side-panel cable from the routing guides on the

chassis.

4 Remove the screw (#6-32x6) that secures the right AlienFX side-panel

connector assembly to the chassis.
