Alienware Area-51 R6

To Next Page

To Previous Page

Procedure

NOTE: Note the routing of all cables as you remove them so that you can

route them correctly after you replace the logo board.

1 Disconnect all the cables from the logo board.

2 Remove the screw (#6-32x6) that secures the logo board to the chassis.
