Removing the antenna cables
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your computer.
For more safety best practices, see the Regulatory Compliance home
page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the stability foot.
2 Remove the left and right side-panels. See “Removing the side panels”.
3 Remove the handle bars.
4 Remove the graphics card.
5 Remove the wireless card.
6 Remove the front bezel.
7 Remove the rear bezel.
Procedure
1 Lay the chassis on the right side.
2 Disconnect the antenna cables from the wireless card.
3 Remove the antenna cables from the routing guide on the chassis.
150
