Replacing the logo board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your computer.
For more safety best practices, see the Regulatory Compliance home
page at
www.dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the logo board to the screw holes on the bracket
and slide the logo board in place.
2 Replace the six screws (#6-32x6) that secure the logo board to the bracket.
3 Slide the logo board inside the chassis.
4 Replace the screw (#6-32x6) that secures the logo board to the bracket.
5 Route and connect the respective cables to the logo board.
Post-requisites
1 Replace the top fan.
2 Replace the left and right side-panels. See “Replacing the side panels”.
3 Replace the stability foot.
87
