18 | About your monitor
Power management modes
If you have VESA's DPM™ compliance displa
y card or software installed on your
computer, the monitor can automatically reduce its power consumption when
not in use. This is referred to as Power save mode*. If the computer detects input
from the keyboard, mouse, or other input devices, the monitor automatically
resumes to function. The following table shows the power consumption and
signaling of this automatic power saving feature.
VESA
modes
Horizontal
sync
Vertical
sync
Video Power
indi
cator
Power
consumption
Normal
op
eration
Active Active Active Blue 110 W
(maximum)**
60 W (typical)
Active-off
mode
Inactive Inactive Blanked White
(bli
nking)
Less than 0.5 W
Switch off - - - Off Less than 0.3 W
AW3418DW
VESA
modes
Horizontal
sync
Vertical
sync
Video Power
indi
cator
Power
consumption
Normal
op
eration
Active Active Active Blue 95 W (maximum)**
50 W (typical)
Active-off
mode
Inactive Inactive Blanked White
(bli
nking)
Less than 0.5 W
Switch off - - - Off Less than 0.3 W
AW3418HW
* Zero power consumption in OFF mode can only be
achieved by disconnecting
the main cable from the monitor.
** Maximum power consumption with max
luminance, and USB active.
Non-operating 12,192 m (40,000 ft) (maximum)
Thermal
dissipation
•375.3 BTU/hour (maximum)
• 204.7 BTU/hour (typical)
• 324.1 BTU/hour (maximum)
•170.6 BTU/hour (typical)

Alienware AW3418DW Specifications

General

3D	No
Pixel pitch	0.2325 x 0.2325 mm
Pixel density	109 ppi
Backlight type	LED
Display surface	Matt
Display diagonal	34.14 \
Screen curvature	1900 mm
Display technology	LCD
Native aspect ratio	21:9
Vertical scan range	30 - 100 Hz
Maximum refresh rate	120 Hz
Horizontal scan range	73 - 151 kHz
Supported video modes	480p, 576p, 720p, 1080p
Viewable size diagonal	867.2 mm
Screen curvature rating	1900R
Viewable size, vertical	334.8 mm
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	799.8 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 3440 x 1440
On/off switch	Yes
Feet color	Black/Silver
Product color	Black, Silver
Front bezel color	Black
Market positioning	Gaming
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
LED indicators	Power
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
Current rating	1.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A++ to E
Power consumption (max)	110 W
Power consumption (off)	0.3 W
Annual energy consumption	77 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	60 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, DisplayPort, Mini DisplayPort, USB
Pallet width	1016 mm
Pallet length	1219.2 mm
Quantity per pallet	2 pc(s)
Pallet volume weight	63550 g
Number of layers per pallet	1 pc(s)
Package depth	934 mm
Package width	449.1 mm
Package height	642.9 mm
Package weight	19270 g
Package material	Corrugated cardboard, Polyethylene terephthalate (PET), Low-density polyethylene (LDPE)
Corrugated cardboard content per package	4220 g
Low-density polyethylene (LDPE) content per package	2660 g
High-density polyethylene (HDPE) content per package	0 g
Polyethylene terephthalate (PET) content per package	70 g

Weight and Dimensions

Stand weight	4590 g
Bezel width (top)	10.45 mm
Bezel width (side)	9.77 mm
Depth (with stand)	319 mm
Width (with stand)	813.6 mm
Height (with stand)	560.8 mm
Weight (with stand)	11860 g
Bezel width (bottom)	18.43 mm
Depth (without stand)	121.37 mm
Width (without stand)	813.45 mm
Height (without stand)	363.68 mm
Weight (without stand)	7270 g
