28 | Setting up the monitor
Connecting the computer
WARNING: Before you begin any of the procedures in this section,
follow the Safety instructions.
NOTE: Do not connect all cables to the
computer at the same time.
To connect your monitor to the computer:
1. Connect the other end of the connected DisplayPort (or Mini-DisplayPort
to DisplayPort), or HDMI cable to your computer.
2. Connect
the upstream USB 3.0 port (cable supplied) to an appropriate
USB 3.0 port on your computer. (See Rear and bottom view for details.)
3. Connect the USB 3.0 peripherals to
the downstream USB 3.0 ports on the
monitor.
4. Plug the
power cables for your computer and monitor into a nearby outlet.
5. Turn
On the monitor and the computer.
If your monitor displays an image, installation is complete. If it does not
disp
lay an image, see Universal Serial Bus (USB) specific problems.
NOTE: The graphics are used for the purpose of
illustration only.
Appearance of the computer may vary.
