Setting up the monitor | 27
7. Connect the necessary cables to the monitor, as shown in the illustration,
and route the cables through the cable-management slot on the stand riser.
a. Po
wer cable
b. Di
splayPort cable or Mini-DisplayPort to DisplayPort cable
c. HDMI cabl
e (optional, cable not included)
d. USB upstream ca
ble
e. USB
downstream cables (optional, cable not included)
NOTE: Route each cable neatly so that the cables will be organized after
the I/O cover is attached.
WARNING: Do not plug-in power cable to the wall outlet or turn on the
monitor u
ntil you are instructed to do so.
8. Sl
ide the I/O cover till it snaps into place.
NOTE: Ensure that the cables are free from obstruction and pass through
the I/O cover and cable-management slot on the stand riser.
