Component Secured to Screw type Quantity Screw image
Power-adapter port System board and palm-
rest assembly
M2.5x4.5 1
Power-button board Palm-rest assembly M2x3 3
USB Type-C port
bracket
System board M2x3 1
System board Palm-rest assembly M2x3 6
Keyboard bracket Palm-rest assembly M1.2x2.4 8
Keyboard Palm-rest assembly M1.2x1.9 33
16
