Removing the display panel
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
3 Remove the display assembly.
4 Remove the display bezel.
Procedure
NOTE: Ensure that the display assembly is placed on a clean and at surface.
1 Remove the four screws (M2x3) that secure the display panel to the display back-cover and antenna assembly.
2 Gently lift the display panel and turn it over.
3 Peel the tape that secures the display-cable connector latch to the display panel.
4 Open the latch and disconnect the display cable from the display panel.
