NOTE: If the rubber grommets are pushed out of the speakers when removing the speakers, push them back in place before
replacing the speakers.
Steps
1. Using the alignment posts, place the left and right speakers into their slots on the palm-rest and keyboard assembly.
2. Route the speaker cable through the routing guides on the palm-rest and keyboard assembly.
3. Adhere the tape that secures the speaker cable to the palm-rest and keyboard assembly.
4. Connect the speaker cable to the system board.
Next steps
1. Install the battery.
2. Install the
base cover.
3. Follow the procedure in After working inside your computer.
Antennas
Removing the antennas
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the wireless card.
5. Remove the
speakers.
About this task
The following image(s) indicate the location of the antennas and provides a visual representation of the removal procedure.
25
