Display assembly
Removing the display assembly
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the
rear I/O-cover.
About this task
NOTE: The display assembly is a Hinge-Up Display (HUD) and cannot be further disassembled.
The following image(s) indicate the location of the display assembly and provides a visual representation of the removal procedure.
36
