8 OPERATOR ADJUSTMENT
See table below and diagrams on page 18 for operator feature adjustment. After adjustment, cycle the door
several times and check for proper operation, then continue with step 6.11 on page 9.
N
Adjust operator for the slowest operation practical in accordance with the latest
AS_5007 standards for powered doors for pedestrian access and egress.
Opening speed 5 sec’s or more Closing speed 3 sec’s or more
OTE
Features Control Description Anti-Clockwise Clockwise
Opening
Speed
P1 Controls opening speed of door Slower Faster
Back Check
Speed
P2 Controls speed of door near full
open position to prevent door
slamming open
Slower Faster
Hold Open
Time Delay
P3 Controls length of time door
remains in the full open
position 1 to 30Sec
Less time
1 Sec
`More Time
30 Sec’s
Auto
Reverse
setting
P4 Sets pressure required on door
opening before door stops
Less Pressure
required
More
Pressure
Required
Latch
Position
P5 Determines distance at which
the door begins to decelerate to
full closed position to prevent
door slamming
Less Latch More Latch
Closing
Speed
P6 Controls closing speed of door Slower Faster
Safety
Opening
Angle
P7 Controls the angle during the
open cycle that safety operates
Closer to closed
position
Further from
closed
position
Closing
Angle
Controls the angle during the
close cycle that safety operates
position
open
position
Delayed
Activation
SW1
Push And Go
SW2 When switched on, pushing the door
open by 5 degrees causes
the operator to open for the
remainder of the open cycle
Power boost
On or OFF
SW3 Enables or disables Power Boost
which gives a force in the closed
direction when the door is closed.
Used for high wind
situations
Power boost
continuous
or 5 Sec’s
SW4 Enables power boost to operate
continuously or for 5 Sec’s only after
door closes.
