Allegion LCN Benchmark AU9100 Series User Manual

Page 17 of 20 December 2014 Ver 4
10.3 FUNCTION CHART
Program BCD Operation
Standard
0
Eyetech Act T1,T2 Eyetech Saf T5,T6
F/A T9,T10 1 Way T27,T28
Door open T14
Key switch off T12
2 Way T22,T23
T8 Not Used
Locking in OFF only
1
As Std
Door locks in OFF Only
Locking Auto only
2
As Std
Door Locks in AUTO Only
Standard PNG in OFF
3
As Std PNG operates in key switch OFF
Fire Alarm to close door
Normally closed
(Breakout)
4
As Std
F/A T9,T10 Normally closed
Door closes and remains unlocked
5
6
7
8
9
A
B
C
D
E
F
