Page 5 of 20 December 2014 Ver 4

4 OPERATOR INSTALLATION

4.1 Remove control box from mounting bracket, then remove Motor/Gearbox from bracket

4.2 Prepare header frame Pull system …………………See Page 5

Push system…………………See Page 6

NOTE

For push units with a reveal greater than 150 mm refer

to installation sheet included in the extended arm

Packaging.

4.3 Install operator-mounting bracket on the header/frame.

4.4 Install motor/gearbox on operator mounting bracket, then install control box on bracket Go to wiring

page 7

Pull System

Framed Header and Door Preparation
