Page 7 of 20 December 2014 Ver 4
5 WIRING
C
CAUTION
Make sure all wires are properly dressed and secured to prevent interference
• Route all wiring away from moving parts, sharp edges, and heat sources
• Use copper conductors only
• Do not modify the factory wiring or connect into existing electrical circuits or
devices
AUTION
5.1 Refer to the appropriate wiring diagram for the standard control box (Page 22) or the
diagram supplied for custom applications. And connect the following cables
• Ground cable (Ground the operator properly with the earth from main
supply
• Hall effect Cable (do not wrap the hall effect cable around the motor cable)
• Motor power cable (do not wrap the motor cable around the hall effect
cable)
• Control box power cable
5.2 Connect Activate, Safety, Key switch, and lock accessories as needed. Refer to the
accessory instruction/s for any accessories used. Do not connect any remote activating
device to the door unless it is located within line of sight of the door
5.3 When wiring is complete go to “Arm and cover installation” on page 8
