ALLEN & HEATH Avantis User Manual

Avantis Getting Started Guide
17
AP11558 Issue 3
9. Te c h n i c a l Specifications
Inputs
System
Mic/Line XLR Inputs
Balanced XLR, +48V phantom power
Measured balanced XLR In to XLR Out, 20-20kHz, minimum Gain,
Pad out
Mic/Line Preamp
Fully recallable
Dynamic Range
112dB
Input Sensitivity
-60 to +15dBu
System Signal to Noise
-98dB
Analogue Gain
+5 to +60dB, 1dB steps
Frequency Response
20Hz - 30kHz (+0/-0.8dB)
Pad
-20dB Active PAD
THD+N
(analogue in to out)
0.0015% @ +16dBu output, 1kHz
0dB gain
Maximum Input Level
+30dBu (PAD in)
Headroom
+18dB
Input Impedance
>4kΩ (Pad out), >10kΩ (Pad in)
Internal operating Level
0dBu
Mic EIN
-127dB with 150Ω source
dBFS Alignment
+18dBu = 0dBFS
(+22dBu at XLR output)
Phantom Power
indication
Per socket, internal or external
phantom power sensing, triggered at
+24V
Meter Calibration
0dB meter = -18dBFS
(+4dBu at XLR out)
Digital Inputs
AES3 2 Ch XLR, 2.5Vpp balanced
terminated 110 Ω
Meter Peak indication
-3dBFS (+19dBu at XLR out)
SRC range 24 bit, 32k - 192kHz, with
bypass option
Sampling Rate
96kHz
Outputs
ADC
32-bit
DAC
32-bit
Analogue XLR Outputs
Balanced, Relay protected
Output Impedance
<75Ω
Nominal Output
+4dBu = 0dB meter reading
Maximum Output Level
+22dBu
Residual Output Noise
-95dBu (muted, 22-22kHz)
Operating Temperature
Range
0 deg C to 40 deg C
32 deg F to 104 deg F
-90dBu (muted, 0-80kHz)
Mains Power
100-240V AC, 50-60Hz, 150W max
Digital Outputs
AES3 2 Ch XLR, 2.5Vpp balanced
terminated 110 Ω
96kHz sampling rate, globally
switchable to 48kHz, 44.1kHz
USB Audio playback
Mono/stereo .WAV files,
16/24bit, 44.1/48/96kHz
USB Audio recording
Stereo .WAV files,
24bit 96kHz
Dimensions and Weights
Unboxed
Boxed
Width x Depth x Height
917 x 627 x 269 mm
36.1" x 24.7" x 10.6"
Width x Depth x Height
1100 x 850 x 425 mm
43.3" x 33.5" x 16.7"
Weight
26kg
57.4lbs
Weight
34kg
75lbs
