ALLEN & HEATH dLive CTi1500 User Manual

CTi-1500 Surface Getting Started Guide
4
AP12150 Issue 1
Packed items
Check you have received the following:
• dLive CTi-1500 Surface
• CAT5 Cable (2m)
• Getting Started Guide AP12150
• Safety Sheet
• IEC mains lead
Contents
IMPORTANT - Read before starting ............................................................................................................ 3
Packed items ................................................................................................................................................ 4
Contents ....................................................................................................................................................... 4
1. Introduction...................................................................................................................................... 5
1.1 dLive Surfaces ........................................................................................................................ 5
2. Rear Panel ....................................................................................................................................... 6
3. Front Panel ...................................................................................................................................... 8
3.1 Harmony UI ........................................................................................................................... 10
3.2 Screen modes ....................................................................................................................... 11
3.3 Fader strip ............................................................................................................................. 12
3.4 Working with the Mix ............................................................................................................. 13
4. Connect and power up .................................................................................................................. 14
4.1 MixRack connection .............................................................................................................. 14
4.2 Recall a Template Show ....................................................................................................... 14
4.3 Expander connection ............................................................................................................ 14
4.4 Connect a laptop or wireless router ...................................................................................... 15
5. Dimensions .................................................................................................................................... 16
6. Technical specs ............................................................................................................................. 17

ALLEN & HEATH dLive CTi1500 Specifications

Inputs System

dynamic range	110 dB
input sensitivity	-60 to +15 dBu
system signal to noise	-92 dB

Power

mains power	100-240V AC
frequency	50-60 Hz
power consumption	110 W max

Operating Environment

operating temperature range	0 deg C to 35 deg C
operating temperature range (Fahrenheit)	32 deg F to 95 deg F
maximum output level	+22 dBu

Weight and Dimensions

unboxed dimensions	440 x 644 x 337 mm
unboxed weight	11.5 kg
boxed dimensions	655 x 820 x 470 mm
boxed weight	20 kg
