SPECIFICATION
7
SONG MEMORIES
127 User programmable memories and the PAUSE patch each store:
Default
Name
8 Characters
SONG n (1-127)
Lock
Off or On Prevents song memory from being overwritten Off
Mute MUTE off (channel on) or MUTE on (channel off)
CH1-8, FX1, FX2, AUX, FB, LR
EQ1 to 8
4-band parametric channel equaliser
HF +/-15dB shelving Sweep from 2kHz to 20kHz
HM +/-15dB bell peak/dip Sweep from 500Hz to 15kHz
Q (width) = 0.2, 0.3, 0.8, 1.7 octave
LM +/-15dB bell peak/dip Sweep from 35Hz to 1kHz
Q (width) = 0.2, 0.3, 0.8 1.7 octave
LF +/-15dB shelving Sweep from 20Hz to 200Hz
-15dB switches to 12dB/octave high pass filter (HPF)
Sweep from 20Hz to 200Hz
OUT = EQ switched in or out of circuit
0dB 8kHz
0dB 2kHz
0.8 octave
0dB 250Hz
0.8 octave
0dB 63Hz
Compressor DRIVE control = How much compression
Combines ratio, threshold, make-up gain
From Off > gentle compression > hard compression
26 steps from 0 (off) to 25 (max) range:
Ratio 1:1 (off) to 16:1 (hard compression)
Threshold –20dB to -10dB
Make-up gain 0dB to 9dB (hard compression)
ATTACK = How fast the compressor responds
RELEASE = How fast the compressor releases
25 steps from 1 (fast) to 25 (slow)
Attack 0.3mS to 300mS
Release 100mS to 10S
KNEE = How sharp the turning point on the gain curve
Hard or soft
Off
13
S (soft)
Gate LEVEL = Threshold level at which the noise gate opens
26 steps from off, -72dB to 0dB
ATTACK = How fast the gate opens as the threshold is reached
25 steps from 1 (0.1mS) to 25 (2S)
DECAY = How fast the gate closes
25 steps from 1 (200mS) to 25 (2S)
Off
7
13
