MIDI SPECIFICATION
MIDI CHANNEL NUMBER
MIDI device ID: Selected from the front panel UTIL screen.
Channel 1 to 16
CHANNEL MUTES
MUTE transmitted: MIDI note on/off message
Note 0xnn
nn = MIDI note number 20 to 2C
m = MIDI device ID
MUTE on transmits note on/off messages:
0x9m 0xnn 0x7F (‘note on’ with velocity >0x40)
0x9m 0xnn 0x00 (‘note off’)
MUTE off transmits:
0x9m 0xnn 0x3F (‘note on’ with velocity <0x40)
0x9m 0xnn 0x00 (‘note off’)
MUTE received: MIDI note on/off message
0x9m 0xnn 0xvv
vv = MIDI velocity
00 = ignore, 01 to 3F = off , 40 to 7F = on
When MIDI activates a mute no message is sent out.
If you are running Cubase on a PC to control your
system then you can access the individual icon
parameters from within the program via MIDI. A set
of MIDI maps for Cubase can be downloaded free
from the Allen & Heath web site.
7 - 8 icon SERIES
