MEMORY RECALL
MIDI control is now extended to the VENUE memory recalls as well as SONG.
These use the same program change messages as before but different banks.
Refer also to the icon User Guide which details the original MIDI functions
including MUTE note on/off messages and system exclusive data archive.
SONG RECALL Program change in Bank 1
0xBm, 0x00, 0x00, 0xCm, pp
Where m is MIDI channel number
pp is 0x00 = SONG 1
0x7E = SONG 127
0x7F = PAUSE
VENUE RECALL Program change in Bank 2
0xBm, 0x00, 0x01, 0xCm, pp
Where m is MIDI channel number
pp is 0x00 = VENUE 1
0x12 = VENUE 19
GLOBAL FUNCTIONS
The following global functions are controlled using MIDI system exclusive
messages.
Where MV is major version number 0… 127
Mv is minor version number 0… 127
m is MIDI channel number
AMP MODE Changes mix source to amplifier channels A and B:
0xF0,0x00,0x00,0x1A,0x50,0x07,MV,Mv,0x0m,0x03,Mode,0xF7
Where Mode is 0x00 for L R
0x01 for FB M
0x02 for Aux FB
AUX PRE/POST Switches all channel aux sends either pre or post fader:
0xF0,0x00,0x00,0x1A,0x50,0x07,MV,Mv,0x0m, 0x05, Pre/Post,0xF7
Where Pre is 0x00
Post is 0x7F
TRIM ON/OFF Enables or disables the channel level trim parameter:
0xF0,0x00,0x00,0x1A,0x50,0x07,MV,Mv,0x0m, 0x04, Off/On,0xF7
Where Off is 0x00
On is 0x7F
icon SERIES 7 - 9
