PARAMETER CONTROL
Every console parameter is mapped for independent MIDI control. This is based
on the NRPN system with the MSB selecting the channel number, and the LSB
selecting the parameter number in that channel (channel type specific).
Channel selection message: 0xBm, 0x63, <Channel>
(Controller 99)
Where <Channel> is 0x00 = CH1 to 0x07 = CH8, 0x08 = FX1, 0x09 = FX2,
and 0x40 = GEQA, 0x41 = GEQB.
Parameter selection message: 0xBm, 0x62, <Param ID>
(Controller 98)
Where <Param ID> is shown below:
Parameter values are set using Data Entry MSB: 0xBm, 0x06, <Value>
All parameter values are ‘normalised’ from 0x00-0x7F
Device Parameter Parameter ID
LF Gain 0x01
LF Frequency 0x02
LMF Gain 0x03
LMF Frequency 0x04
LMF Q 0x05
HMF Gain 0x06
HMF Frequency 0x07
HMF Q 0x08
HF Gain 0x09
HF Frequency 0x0A
PEQ
In/Out 0x0B
Drive 0x0C
Attack 0x0D
Release 0x0E
Knee 0x0F
Compressor
In/Out 0x10
Level 0x11
Attack 0x12
Decay 0x13
Gate
In/Out 0x14
Aux Send Level 0x15
Foldback Send Level 0x16
Trim Level 0x17
Pan/Balance Pan/Balance 0x18
FX1 Send Level 0x19
FX2 Send Level 0x1A
Fader Level Level (transmit only, no recieve) 0x1B
Band Gain 0x00 Lowest Band 31Hz
0x09 Highest Band 16kHz
In/Out 0x20
GEQ
Linking 0x21
When linked, both GEQA&B messages (for
band gain & in/out) are generated by the I-CON
7 - 10 icon SERIES
