• Rear panel
: AC 100 – 240V ~
: RS232 (Modem). This port needs to be activated from within the System manager software.
: MDI/X switch
: TX, Link LEDs
: Network port
No MIDI
: Rear RS232 Sysnet port. Indicator LED. This port needs to be activated from within the
System manager software.
: PL-ANET. This port needs to be activated from within the System manager software.
: DR-LINK
: AUDIO IN
: AUDIO OUT
: Analog audio. 2x balanced XLR in, 4x balanced ¼” jack in
4x balanced XLR out, 2x balanced ¼” jack out
Total i/o = 6 IN, OUT

ALLEN & HEATH iDR Series Specifications

General

EQ Bands	4-band parametric EQ per channel
Word Length	24-bit
Dynamic Range	>110dB
THD+N	<0.005%
Control	Ethernet
Connectivity	Ethernet
Audio Processing	96kHz
Mounting	Rackmount
Faders	None (controlled via external surfaces)
Effects	Reverbs, Delays, Modulations
Sampling Rate	96 kHz
