ALLEN & HEATH ME-1 User Manual

User Guide – AP8997 iss.3 24 ALLEN&HEATH
8.2 Setup mode
Hold Shift and press the Group key to enter
the Setup Menu:
Use the Rotary to scroll through the list and
press to select a menu item.
Press the Master key to return to the previous
screen.
Press the Group key to return to Normal
mode.
8.3 Adjusting the brightness
Scroll to the Dimmer menu:
There are two settings. Press the Rotary to
toggle bright or dim. The dimmer affects the
screen and key brightness.
8.4 The About screen
Select the About screen:
This screen displays information about the
ME-1 mixer:
 Current Configuration name (the settings)
 Current Unit name (the mixer)
 Current operating Firmware version
 MAC address (factory programmed)
8.5 Assigning Key Sources
The audio source for each of the 16 Select
keys can be freely assigned to suit your
application.
Select the Key Setup Source screen:
A list of available sources is displayed. Use
the Rotary to scroll through and press to
select the required source:
Unassigned – The key does not select any
audio source. Choose when you want to
leave keys unused or used for presets only.
Group – Sets the key to be a group with a
master affecting the overall level of all
channels assigned as its members. For
example a ‘Drums’ or ‘Vocals’ group.
Aux Input – Selects the local stereo line input
available on the rear of the mixer.
Auto Mode – The key automatically assigns
the first available channel not already
assigned.
1kHz Sine – A sine wave tone for testing and
setting levels of equipment connected to the
ME-1 outputs.
Channels 1-40 – Assign an individual source
to the key from one of up to 40 channels
received via the Cat5 cable.
Note Stereo channel pairs assign to single
keys if stereo link data is received from the
connected source (GLD, ME-U, Aviom
®
).
Note The source list will display channel
names if these are received from the
connected source (GLD, ME-U).
Dimmer
About
System Setup
Press Group to exit
Key Setup
Dimmer
About
Key Setup
Press Group to exit
System Setup
Config: MATT
Unit: MM4
Firmware: V1.00r9057
Mac:
00:04:C4:00:73:3A
Source: Unassigned
Name:
Members:
Preset:
StoreRecall
Unassigned
Group
Aux Input
Auto Mode
1kHz Sine
Source:
USO RESTRITO

ALLEN & HEATH ME-1 Specifications

Audio Output

stereo out power	300+300mW into 100 Ω
mono out max level	+18dBu
aux input max level	+10dBu

Power

mains power unit	100-240V AC 50/60Hz
power over ethernet requirement	10W

Weight and Dimensions

dimensions	225 x 150 x 55mm
weight	900g
