ALLEN & HEATH ME-1 User Manual

User Guide – AP8997 iss.3 32 ALLEN&HEATH
9.4 Specification
Stereo Out – Stereo ¼” and 3.5mm jacks for:
Headphones >16 Ω , power 300+300mW
into 100 Ω load, or line out max +21dBu
Mono Out – Balanced TRS jack, nom 0dBu,
max +18dBu
Aux Input – Stereo 3.5mm jack, nom -8dBu,
max +10dBu, impedance >10kΩ
Residual Output Noise - -95dBu (level min)
Freq Response - +0/-1dB 10Hz to 20kHz
Mains Power Unit – 100-240V AC 50/60Hz,
+12V DC 1.25A out
PoE Requirement – 10W at ME-1 (We
recommend 15W at PoE hub)
Dimensions – Width x Depth x Height
225 x 150 x 55mm (8.9” x 5.9” x 2.2”)
Weight – 900g (2lbs) inc phones hook
USO RESTRITO

ALLEN & HEATH ME-1 Specifications

Audio Output

stereo out power	300+300mW into 100 Ω
mono out max level	+18dBu
aux input max level	+10dBu

Power

mains power unit	100-240V AC 50/60Hz
power over ethernet requirement	10W

Weight and Dimensions

dimensions	225 x 150 x 55mm
weight	900g
