XONE:02 Service Manual 13
Order Codes
The following products and parts can be ordered from Allen & Heath or the approved dealer:
XONE:92/v XONE:92 6 stereo channel club mixer with MIDI /v = specify voltage
XONE:02/v XONE:02 2 channel DJ scratch mixer /v = specify voltage
XONE:32/v XONE:32 3 channel DJ mixer /v = specify voltage
XONE2:62/v XONE:62 6 stereo channel club mixer /v = specify voltage
XONE2:464/v XONE:464 4 mic 6 stereo channel mixer /v = specify voltage
XONE:V6/v XONE:V6 Rotary DJ mixer /v = specify voltage
XONE:V6-EQISO XONE:V6 EQ Isolator module
XONE:V6-XFADER XONE:V6 Cross-fader module
XONE:V6-VALVE XONE:V6 all valve option
002-779 45mm Stereo Channel Fader for XONE:02
002-780 45mm Crossfader for XONE:02
AP4264 XONE:02 User Guide
AP4501 XONE:02 Service Manual
SERVICE TOOLS
The tools required to service the XONE:02 are standard to an electronics service workshop and are
easily obtainable. The following items are necessary for disassembly and service access:
TOOL USE ORDER CODE
T10 Torx-headed screwdrivers M3, 4AB Torx-headed screws
1-point Crosshead screwdriver M2.5 Torx-headed screws AT0004
0-point Crosshead screwdriver M2 Torx-headed screws
2BA or 8mm AF Spanner 2BA Earth post on rear
5.5mm AF Spanner or Nutdriver M3 Earth post inside
11mm AF Nutdriver
Potentiometer and headphone socket
nuts
12mm Nutdriver Jack nuts
