ALLEN & HEATH XONE 02 Service Manual

XONE:02 Service Manual 3
Contents
Important Safety Instructions ...................... 4
Key Features............................................... 5
Front and Rear Panel Layouts .................... 5
Specifications .............................................. 6
Xone:02 Block Diagram .............................. 7
Earthing....................................................... 8
Cables and Connections............................. 9
Gain and Operating Levels ....................... 10
Replacing the Faders ................................ 11
Tips and Troubleshooting.......................... 12
Order Codes.............................................. 13
Ordering an Assembly............................... 14
Ordering a Xone:02 Spares Kit ............ 15-17
TECHNICAL DRAWINGS..............................
INTERNAL LAYOUT................................. D1
MAIN/MIC/CONN PCB ............................. D2
MAIN/MIC/CONN PCB .......................... D2.1
MAIN/MIC/CONN CONNECTOR CCT..... D3
MAIN/MIC/CONN CONNECTOR CCT.. D3.1
MAIN/MIC/CONN EQ CCT ....................... D4
MAIN/MIC/CONN EQ CCT .................... D4.1
MAIN/MIC/CONN MIC INPUT CCT.......... D5
MAIN/MIC/CONN MIC INPUT CCT....... D5.1
MAIN/MIC/CONN PSU CCT..................... D6
MAIN/MIC/CONN PSU CCT.................. D6.1
MAIN/MIC/CONN VCA CTRL CCT .......... D7
MAIN/MIC/CONN VCA CTRL CCT ....... D7.1
MAIN/MIC/CONN VCA MIX AMP CCT..... D8
MAIN/MIC/CONN VCA MIX AMP CCT.. D8.1
MASTER/MAINS/METERS PCB .............. D9
MASTER/MAINS/METERS MSR CCT... D10
MSTR/MAINS/METERS MAIN CCT....... D11

ALLEN & HEATH XONE 02 Specifications

General

Brand	ALLEN & HEATH
Model	XONE 02
Category	Music Mixer
Language	English
